Hot Water Steam Sterilizer

Get a Price/Quote

MOQ : 10 Units

Hot Water Steam Sterilizer Specification

Type
Horizontal, Automatic

Chamber Size
1000 x 600 x 600 mm

Chamber Thickness
6 mm (316L Stainless Steel)

Outer Size
1680 x 980 x 1800 mm

Compressed Air
0.5-0.7 MPa

Door Type
Double Hinged Door

Design Pressure
0.25 MPa

Working Pressure
0.15-0.17 MPa

Design Temperature
134C

Heat Uniform
1C throughout chamber

Insulation
High-density PU/Glass Wool

Net Weight
Approx. 850 kg

Recording Parameters
Digital Printer & USB Data Logger

Spraying Mode
Multi-directional Spray Nozzles

Outer Trolley
Stainless Steel, Removable

Inner Trolley
Perforated Stainless Steel, Adjustable Shelves

Spraying Piping
316L Stainless Steel, Tri-clamp Fittings

Steam
Saturated Steam, External Source

Sterilizing Temperature
121C

Working Temperature
121C

Sterilization Time
30 minutes (adjustable)

Temperature Scope
80C to 134C

Piping System
316L Stainless Steel, Sanitary Design

Valves
Sanitary Pneumatic & Manual Type

Power Consumption
8 kW

Water Circulation
Internal, High-Efficiency Pump

Control System
PLC with Touchscreen Interface

Safety Features
Automatic Door Lock, Overpressure Protection, Overheat Cut-off

Drainage System
Automatic, Sterile Drain

Optional Features
Inbuilt Pure Steam Generator, Remote Monitoring Module

Power Supply
380V / 50Hz / 3 Phase

Standard Accessories
Loading Trolleys, Validation Ports, Spare Gaskets

Noise Level
< 65 dB

Installation
Floor Mounted

Material of Construction
316L Stainless Steel (GMP Compliant)

Compliance
cGMP, CE Marked, ISO 9001 Certified

Hot Water Steam Sterilizer Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Hot Water Steam Sterilizer

Personalise your sterilization process with our Hot Water Steam Sterilizer, meticulously engineered from superior 316L stainless steel for unprecedented durability and GMP compliance. Procure this pivotal solution equipped with an advanced PLC control system and intuitive touchscreen interface, ensuring operational ease and compliance. Safety is paramount, with automatic door lock, overpressure protection, and overheat cut-off. An internal high-efficiency pump, sanitary design, and multi-directional spray system deliver uniform sterilization. Enjoy unbeatable price advantages, unmatched reliability, and complete certification, making this sterilizer the universally trusted choice for laboratories and pharmaceutical manufacturers in India and globally.

Applications & Features of Hot Water Steam Sterilizer

Ideal for pharmaceutical, medical, and laboratory setups, this Hot Water Steam Sterilizer ensures efficient and validated sterilization of equipment and media. Its automatic, horizontal design and adjustable temperature range (80C to 134C) make it perfect for specific and diversified usage, including the sterilization of sensitive instruments. Additional features such as PLC touchscreen control, multi-directional spray nozzles, and digital data recording enable reliable results and superior user experience.

Supply Capability & Purchase Information

Our company ensures strong supply ability for the Hot Water Steam Sterilizer throughout the main domestic markets of India. Samples are readily available upon request. Listing price is determined based on configuration, with freight calculated separately. To procure this equipment, simply submit a purchase order; our team coordinates all logistics to guarantee safe delivery and compliant installation. Reliable after-sales service and accessories are included for seamless operations, ensuring customer confidence and satisfaction.

FAQ's of Hot Water Steam Sterilizer:

Q: How does the Hot Water Steam Sterilizer ensure safety during operation?

A: The sterilizer incorporates automatic door locking, overpressure protection, and overheat cut-off systems, ensuring safe operation throughout the sterilization cycle.

Q: What materials are used in the construction of this sterilizer?

A: The chamber and piping system are constructed from 316L stainless steel, ensuring corrosion resistance, sanitary design, and compliance with cGMP, ISO 9001, and CE standards.

Q: When can the Hot Water Steam Sterilizer be used for optimal efficiency?

A: It is designed for routine and high-demand sterilization processes in pharmaceutical, laboratory, and healthcare settings, offering efficient sterilization with a 30-minute adjustable cycle at 121C.

Q: Where can this sterilizer be installed?

A: This floor-mounted sterilizer is suitable for installation in pharmaceutical industries, hospitals, and research laboratories where validated and high-volume sterilization processes are required.

Q: What are the key benefits of the PLC touchscreen control system?

A: The PLC touchscreen system offers intuitive operation, programmable cycles, precise temperature control, and real-time monitoring, simplifying sterilization management and reducing operator training time.

Q: How is uniform heat ensured throughout the chamber during sterilization?

A: The sterilizer utilizes a multi-directional spray nozzle system and a high-efficiency internal pump, providing consistent temperature distribution (1C) for effective sterilization results.
